The latest washing system in the Frontloader family is the Mustang, which can be delivered in the following four versions: C90, 130, 150 and 200. The machine comes as standard as a two stage system. This means that the system can be used for the following processes: wash – rinse, wash – passivate or wash – phosphate. The system has an extremely robust construction, which without problems can handle parts up to 2000 kg.
Operation of the machineThe parts to be cleaned are sprayed like the DF-series with a high flow via the spray bars, which rotate either through spray pressure or a mechanical drive. The spray bars are mounted with flat pattern nozzles, which provide efficient cleaning results. |
Design and user friendlinessThe Mustang is designed in a compact and simple way. Even though the Mustang is constructed to handle a lot of different jobs, it is still important that the machine is not complex – either to look at or operate. The systems are prepared for mounting different optional extras such as drying and filtration units, oil skimmers, extraction fan/steam condenser, discharge pump and chemical dosing. All the extra units can be integrated in the machine without external components, which means that it still is a compact machine with straight lines. |
EquipmentThe Mustang comes as standard with the vision 3000 control, which makes it easy to programme different wash cycles. The Mustang can also be delivered with Siemens PLC S7/200 with appurtenant soft touch panel. There is a large selection of optional extra equipment for the Mustang. Click here to find out more. |
